Leo SEC075T-1 3/4 HP Submersible Sewage Pump
-
Description
Leo SEC075T-1 Submersible Sewage Pump
The Leo SEC075T-1 is a 3/4 HP submersible sewage pump used to pump out liquids and solids up to 2 in. diameter. The most common application is for septic systems or sewage pits.
Features
- Durable cast iron construction
- Heavy duty cast iron volute and nylon impeller
- Built-in automatic thermal overload protector motor
- Adjustable tethered or piggy back float switch for automatic operation
- Application up to 2″ diameter solids
- 2″ NPT discharge
- 10ft power cord
Specifications
- Inlet: 2 inch
- Discharge: NPT2
- Motor Housing: 08F
- Pump Body: HT200
- Switch Type: Float Switch
- Impeller: PA6-GF25
- Seal Design: Mechanical Seal
- Seal Material: Carborundum & Carborundum
- Oil Filled Motor: Yes
- Power Cord: SJTW3*18AWG
- Net Weight: 32
- Gross Weight: 34
- Package Size: 11.2×7.5×17.1
- Expected Life Cycle: ON 10 Sec. OFF 30 Sec. 100,000 Cycles
- Motor Wires: Copper
- Self-Priming: No
- Certification: CSA
Model HP Voltage AMP Discharge NPT(in) Max. Head Ft GPH of water @ Total Ft. of Head 5 ft 10 ft 15 ft 20 ft 25 ft SEC075T-1 .75 (3/4) 120 9.5 2 31 7500 6400 5400 4600 3700 -
Additional information
Product Category Sewage Pumps, Submersible Pumps Series SEC075T Manufacturer Leo Models - Technical Data
- SEC075T-1
Horsepower 3/4 Voltage 120 Part Number SEC075T-1 -
Technical Data
